Rotary Burnout Furnace, It gives excellent casting result of Gold, Silver and Brass jewelery because of this feature which enables precise, rapid and user friendly operation. The thermocouple ensures safe and reliable stone casting monitoring the temperature to the nearest degree to ensure that valuable stones are not over heated .Space saving technology for maximum utilization of space. De-waxing tray is provided at the bottom.
Advantages and Features:
Key advantages of the Rotary Burnout Furnace include:
Rotary Mechanism: Enables even heat distribution throughout the chamber, ensuring uniform heating and consistent mold preparation.
Customizable Settings: Allows for precise temperature control, catering to the specific requirements of different materials and casting processes.
Space-Efficient Design: Compact yet efficient design maximizes space utilization, accommodating multiple flasks for simultaneous processing.
Durable Construction: Incorporates high-grade materials, ensuring durability and longevity while minimizing heat loss.
Rotary Burnout Furnace. The stainless steel chamber protects damage of heating elements from carbon deposits, thus increase the life of heating elements. The high quality of heating insulation reduces energy consumption as compared to the other conventional burnout furnace. The revolving table further improves heat transfer within the furnace during the burnout cycle. Following Burnout Cycle the chimney valves can be opened and closed to keep flasks as per the required temperature until last casting. Various types of ceramics products which has low thermal mass are used for insulation in the furnace. To ensure minimum wastage of electricity we have used high quality of electronic panel with SSR controller PID temperature controller along with the safety temperature controller. We also provide Multi step program (optional).
Technical Specification:-
MODEL NO
FLASK NO
CHAMBER SIZE
BODY SIZE
AST RPF06
6
17″
35″W x 34″D x 54″H
AST RPF08
8
20″
39″W x 38″D x 54″H
AST RPF12
12(6X2)
16″
35″W x 34″D x 56″H
AST RPF14
14(7X2)
18″
37″W x 36″D x 56″H
AST RPF 20
20(10X2)
23″
39″W x 38″D x 56″H
AST RPF 36
36(18X2)
27″
46″W x 45″D x 60″H
AST RPF 52
52(26X2)
34″
53″W x 51″D x 60″H
